This guide will show you how to disassemble a Honeywell Turbo Force Air Circulator Fan, so cleaning the interior of the fan is easier. It will also allow for further actions to take place such as oiling the rotor of the fan.
Honeywell Turbo Force 12" Air Circulator.
Dimensions - 11.22" x 9.8" x 13.98", 5.7 lbs.
Remove the 6 screws from the backside of the fan.
Remove the front grill cover.
Remove the inside plastic ring around center shaft.
Enables the fan blades to be removed.
Use a flat head screwdriver to remove the plastic ring.
Remove the fan blades by pulling.
Remove 1 screw inside to detach the plastic wire covering.
Remove the plastic covering.
Remove the 2 screws on the motor.
This allows the motor to pull away from the housing.
Pull the motor away from the housing to expose wiring.
Use caution to not detach the wiring from the back.
Remove the two screws from the back of the motor.
Allows the rotor and front/back bearings to be removed.
Remove the rotor and front bearings by pulling.
During reassembly, re-align the bearings by tapping on the shaft.
-
